BL RACKMOUNT 2U
Hover to Zoom
Phoenix Contact · Screw Connection

BL RACKMOUNT 2U

Order No: 2400063

19", 2U rack-mount PC with an Intel® Core™ i3-9100TE or Intel Core™ i7-9700TE 2.40 GHz processor and up to 32 GB of RAM. Mass storage options up to 8 TB. PCI and PCIe expansion slots are open for expansion.

Form Factor 19" 2U Rackmount
Processor Intel® Core™ i3 / i7
Memory (RAM) Up to 32 GB DDR4
Storage Up to 8 TB SATA SSD/HDD
Expansion 3x PCI + 2x PCIe
Power Supply 500 W Industrial PSU
Email Sales Desk
Engineering Value

Your Advantages with Phoenix Contact BL RACKMOUNT 2U

Standard Industrial 19-inch Architecture
✓

Tailored to the 19" rack format

Compact 2U form factor optimized for standard industrial server cabinets and control rooms.

✓

2 swappable drive trays

Dual hot-swappable 2.5" / 3.5" SATA drive bays for high-capacity mass storage up to 8 TB.

✓

Lockable Front Security Door

All front-facing components, power switches, and USB ports are secured under a rugged lockable door.

✓

Toolless Easy Maintenance

Hot-swappable and washable front fan filter prevents industrial particulate buildup and minimizes downtime.

Technical Data Reference Sheets

Comprehensive Technical Specifications

Generated from the official online catalog for Phoenix Contact Order Number 2400063.

01

Notes & Regulatory Compliance

Industrial application constraints and cybersecurity compliance roadmap

2 Parameters
Note on application
 Only for industrial use
EU Cyber Resilience Act (CRA)
 As things stand now, we are preparing the product so that, as of December 11, 2027, it will comply with the requirements of the EU Cyber Resilience Act (CRA) based on the information currently available regarding the CRA.
02

Product Properties

Core product classification and security design properties

3 Parameters
Product type
 Rackmount PC
Special properties
 The product is being prepared for compliance with the Cyber Resilience Act (CRA)
Industrial Class
 Heavy Industrial Automation & Control Room Grade
03

Computer Data & Architecture

Processors, operating systems, memory, storage options, and expansion slots

9 Parameters
Processor Options
 • Intel® Core™ i3-9100TE 2.2 GHz (4 Cores / 4 Threads)
• Intel® Core™ i7-9700TE 1.8 GHz (8 Cores / 8 Threads, up to 2.40 GHz turbo)
Operating System Options
 • without operating system
• Windows® 10 IoT Enterprise LTSC 2019 (64-bit), Multi-language
• Windows® 11 IoT Enterprise LTSC 2024 X64
RAM Configurations
 • 32 GB DDR4 SODIMM
• 16 GB DDR4 SODIMM
• 8 GB DDR4 SODIMM
Data Storage System
 • without data storage, empty drive tray for 2.5" and 3.5" SATA drives
• 1 TB HDD 3.5" SATA
• 2 TB HDD 3.5" SATA
• 4 TB HDD 3.5" SATA
• 240 GB SSD
• 480 GB SSD (Total capacity scalable up to 8 TB)
Cooling System
 Active industrial cooling with hot-swappable and changeable front fan filter
PCI / PCIe Option
 Open PCI and PCIe slots for plug-in fieldbus & vision capture cards
Hardware RAID System
 RAID 0, RAID 1 supported
Expansion Slots
 • 3x PCI
• 1x PCIe x4
• 1x PCIe x16
Optical Drive
 • DVD-RW
• without drive
04

Display & Graphics

Video processing capabilities and integrated graphic engine

5 Parameters
Display type
 without display (headless industrial rackmount PC)
Screen resolution
 without
Touch technology
 Without touch technology
Display lighting type
 without
Graphics card
 Intel® HD Graphics (integrated video engine with hardware acceleration)
05

Electrical Properties & Power Supply

Input voltage ranges, internal power supply rating, and real-time backup

4 Parameters
Service life of battery
 5 years (typical)
Supply voltage
 120 V AC (240 V AC nominal, auto-ranging 100 V AC ... 240 V AC)
Power supply unit (PSU)
 500 W Industrial Active PFC High-Efficiency Power Supply
Real-time clock (RTC)
 Yes (battery-backed with industrial lithium coin cell)
06

Interfaces & Communication Ports

Serial COM channels, high-speed USB, video output, and dual Gigabit Ethernet

5 Parameters
Serial Interfaces
 • 1x COM (RS-232 / RS-422 / RS-485 switchable)
• 1x COM (RS-232 standard D-SUB 9)
USB Ports
 • 4x USB 2.0 (Front & Rear)
• 2x USB 3.0 (High-Speed SuperSpeed USB)
Monitor Output
 1x DVI-D digital video output
Network Interfaces
 2x Ethernet (10/100/1000 Mbps Gigabit LAN), RJ45 with LED indicators
LAN Chipsets
 • Intel® I210-AT Gigabit Network Controller
• Intel® I217 Physical Layer Gigabit Transceiver
07

Dimensions & Material Specifications

Rack enclosure dimensions, structural steel construction, and surface finish

7 Parameters
Width
 482 mm (19-inch standard)
Height
 88.6 mm (2U rack units)
Depth
 429.2 mm
Note on dimensions
 2U 19-inch standard EIA rack mount format
External dimensions (W / H / D)
 482 mm / 88.6 mm / 429.2 mm
Housing Color
 black (RAL 9005 powder-coated)
Housing Material
 Heavy-duty Electrogalvanized Steel (SECC)
08

Environmental & Real-Life Conditions

Operating temperature, vibration resistance, shock testing, and ingress protection

7 Parameters
Degree of protection
 IP20 (dust-protected industrial cabinet rating)
Ambient temperature (operation)
 0 °C ... 55 °C (Configuration options can affect the operating temperature. See user manual for details)
Ambient temperature (storage / transport)
 0 °C ... 70 °C
Permissible humidity (operation)
 5 % ... 95 % (non-condensing)
Permissible humidity (storage / transport)
 5 % ... 95 % (non-condensing)
Mechanical Shock Resistance
 15g in all directions in accordance with IEC 60068-2-27
Vibration Resistance (operation)
 DIN EN 60068-2-6 compliance for continuous industrial vibration
09

Mounting & Installation

Mounting orientation and server cabinet rail holder standard

2 Parameters
Mounting type
 Rack mounting
Holder system
 19" rack server rail brackets
